General
Evaporating Temp. Range: |
-15°C to 15°C (5°F to 59°F) |
Motor Torque: |
Low Start Torque (LST) |
Compressor Cooling: |
Fan |
Mechanical
Weight: |
12 |
Weight Unit of Measure: |
KG |
Displacement (cc): |
11.4 |
Oil Type: |
Polyvinylether |
Viscosity (cSt): |
68 |
Oil Charge (cc): |
414 |
Electrical
Voltage Range (50 Hz): |
207-253 |
Voltage Range (60 Hz): |
207-253 |
Locked Rotor Amps (LRA): |
25 |
Rated Load Amps (RLA 50 Hz): |
2.6 |
Rated Load Amps (RLA 60 Hz): |
3.8 |
Max. Continuous Current (MCC in Amps): |
5.6 |
Motor Resistance (Ohm) - Main: |
2.5 |
Motor Resistance (Ohm) - Start: |
6.7 |
Motor Type: |
PSC |
Overload Type: |
N/A |
Relay Type: |
N/A |
Agency Approval
| CCC Listed, CE Listed, UL Recognized |
